Blackburn LCN1-12 Copper Test Point 2-Hole Lug Long Barrel 1 1/2B Green

Overview

Blackburn LCN1-12 Copper Test Point 2-Hole Lug Long Barrel 1 1/2B Green

Product Specifications

• UPC: 78378603278
• Pad Hole Spacing: 1-3/4 Inch
• Stud Size: 1/2 Inch
• Color: Green
• Material: Tin Plated Copper
• Overall Length: 4-13/32 Inch
• Approval: UL E9809
• Catalog Number: LCN1-12
• Voltage Rating: 35 Kilovolt
• Conductor Material: Copper
• Conductor Size: 1 AWG
• Barrel Type: Long
• Barrel Length: 1-1/32 Inch
• Pad Size: 3 Inch Length x 7/8 Inch Width x 3/32 Inch Thickness
• Number Of Pad Holes: 2
• Catalog Description: TYPE LCN COPPER TWO-HOLE LUG, LONG BARREL, MAX 35KV, WIRE SIZE 1 STR, 1/2 INCH BOLT HOLE, TIN PLATED, DIE COLOR CODE GREEN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Copper Material; Green Color; 4-13/32 Inch Overall Length; 1-1/32 Inch Barrel Length; Copper Conductor Material; UL E9809 Approval; 35 Kilovolt Voltage Rating; 1 AWG Conductor Size; 1/2 Inch Stud Size; 3 Inch Length X 7/8 Inch Width X 3/32 Inch Thickness Pad Size; 2 Pad Hole(S); 1-3/4 Inch Pad Hole Spacing; Long Barrel Type
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786032785
• SKU Name: lcn112 blackburn
