Blackburn LCN4-14 Copper Test Point 2-Hole Lug Long Barrel 4 1/4B Gray

Overview

Blackburn LCN4-14 Copper Test Point 2-Hole Lug Long Barrel 4 1/4B Gray

Product Specifications

• UPC: 78378603273
• Pad Hole Spacing: 5/8 Inch
• Stud Size: 1/4 Inch
• Color: Gray
• Material: Tin Plated Copper
• Overall Length: 2-3/16 Inch
• Approval: UL E9809
• Catalog Number: LCN4-14
• Voltage Rating: 35 Kilovolt
• Conductor Material: Copper
• Conductor Size: 4 AWG (Stranded)
• Barrel Type: Long
• Barrel Length: 25/32 Inch
• Pad Size: 1-3/16 Inch Length x 17/32 Inch Width x 3/16 Inch Thickness
• Number Of Pad Holes: 2
• Catalog Description: TYPE LCN COPPER TWO-HOLE LUG, LONG BARREL, MAX 35KV, WIRE SIZE 4 STR, 1/4 INCH BOLT HOLE, TIN PLATED, DIE COLOR CODE GRAY
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Copper Material; Gray Color; 2-3/16 Inch Overall Length; 25/32 Inch Barrel Length; Copper Conductor Material; UL E9809 Approval; 35 Kilovolt Voltage Rating; 4 AWG (Stranded) Conductor Size; 1/4 Inch Stud Size; 1-3/16 Inch Length X 17/32 Inch Width X 3/16 Inch Thickness Pad Size; 2 Pad Hole(S); 5/8 Inch Pad Hole Spacing; Long Barrel Type
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786032730
• SKU Name: lcn414 blackburn
