Leviton 5225 Comb-Sp Ac Switch & Receptacle 5-15R

Overview

Leviton 5225 Comb-Sp Ac Switch & Receptacle 5-15R

Product Specifications

• UPC: 07847722650
• Application: Commercial
• Approval: UL 20, CSA C22.2, NOM 057
• Additional Information: Applicable Standard ANSI; Actuator Material Thermoplastic; Strap Material Steel; Power Rating 1/2 HP at 120 V; Temperature Rating -40 to 65 Deg C
• Catalog Number: 5225
• Type: Duplex
• Switch Type: 120 VAC 15 Ampere 1-Pole Toggle
• Receptacle Type: NEMA 5-15R 125 VAC 15 Ampere with Grounding Straight Blade
• Wiring: Side
• Wall Plate Included: No
• Material: Thermoplastic
• Color: Brown
• Catalog Description: 15 AMP, 120 VOLT, DUPLEX STYLE COMBINATION SINGLE POLE SWITCH/RECEPTACLE GROUNDING, BROWN
• Category: Combination Devices
• Full Technical Description: Duplex Type; Thermoplastic Material; Brown Color; UL 20, CSA C22.2, NOM 057 Approval; Commercial Application; 120 VAC 15 Ampere 1-Pole Toggle Switch Type; Side Wiring; No Wall Plate Included; NEMA 5-15R 125 VAC 15 Ampere With Grounding Straight Blade Receptacle Type; Applicable Standard ANSI; Actuator Material Thermoplastic; Strap Material Steel; Power Rating 1/2 HP at 120 V; Temperature Rating -40 to 65 Deg C
• Manufacturer: Leviton Mfg. Co., Inc.
• Manufacturer Brand: Leviton Mfg. Co., Inc.
• Sub Category: Combination Switch/Receptacle
• Unspsc: 39122231
• UPC 12 Digit: 078477226506
• SKU Name: lev 5225
