Panduit P14-8F-M Fork Non-Insulated 16-14Awg #8 Pk1000

Overview

Panduit P14-8F-M Fork Non-Insulated 16-14Awg #8 Pk1000

Product Specifications

• UPC: 07498380511
• Temperature Rating: 302 DEG F
• Standard Package: 1000
• Approval: UL, CSA C22.2
• Additional Information: SIZE 0.69 INCH L X 0.31 INCH W; MATERIAL ELECTROLYTIC TIN PLATED COPPER; BARREL TYPE BRAZED SEAM
• Catalog Number: P14-8F-M
• Brand Name: Pan-Term[R]
• Model: P-F
• Type: BEVELED
• Minimum Conductor Size: 18 AWG
• Maximum Conductor Size: 14 AWG
• Insulation Type: NON INSULATED
• Stud Size: #8
• Catalog Description: FORK TERMINAL, NON-INSULATED, 18- 14 AWG, #8 STUD SIZE, BULK PACKAGE.
• Category: Small Terminals & Connectors
• Full Technical Description: Beveled Type; 18 AWG min. Conductor Size; 14 AWG Max. Conductor Size; UL, CSA C22.2 Approval; 302 Deg F Temperature Rating; 1000 Standard Package; #8 Stud Size; Non Insulated Insulation Type; PAN-TERM[R] Brand; Size 0.69 Inch L X 0.31 Inch W; Material Electrolytic Tin Plated Copper; Barrel Type Brazed Seam; P-F Model
• Manufacturer: PANDUIT CORPORATION
• Sub Category: Fork Lug
• Unspsc: 39121409
• UPC 12 Digit: 074983805112
• SKU Name: pand p148fm

Resources

• Manufacturer Spec Sheet
• Technical Drawing
