B-Line B22SH-120GLV Channel, 1-5/8" X 1-5/8", 9/16" X 1-1/8" Slotted-Holes, 12 Ga, 120" Galvanized

Overview

B-Line B22SH-120GLV Channel, 1-5/8" X 1-5/8", 9/16" X 1-1/8" Slotted-Holes, 12 Ga, 120" Galvanized

Product Specifications

• UPC: 78101121330
• Height: 1-5/8 Inch
• Center Spacing: 2 Inch
• Hole/Slot Size: 1-1/8 Inch Length x 9/16 Inch Width (Slot)
• Material: ASTM A653 Carbon Steel
• Process: Cold Formed
• Finish: Pre-Galvanized
• Column Load Rating: 1418 Pound
• Beam Load Rating: 340 Pound
• Deflection: 1.403 Inch
• Weight: 1.82 Pound per Foot
• Catalog Number: B22SH-120GLV
• Type: Metal Framing
• Number Of Channels: 1
• Configuration: Slotted
• Cross Section Area: 0.562 Square Inch
• Thickness: 12 Gauge
• Length: 120 Inch
• Width: 1-5/8 Inch
• Catalog Description: EATON B-LINE SERIES STRUT CHANNEL, 1.62" H X 120" L X 1.62" W, STEEL, PRE-GALVANIZED, SH, 12 GAUGE
• Category: Channel & Strut
• Full Technical Description: Metal Framing Type; ASTM A653 Carbon Steel Material; Pre-Galvanized Finish; 120 Inch; 1-5/8 Inch; 1-5/8 Inch; Slotted Configuration; 12 Gauge Thickness; Cold Formed Process; 1.82 Pound Per Foot Weight; 2 Inch Center Spacing; 1 Channel(S); 1-1/8 Inch Length X 9/16 Inch Width (Slot) Hole/Slot Size; 1.403 Inch Deflection; 0.562 Square Inch Cross Section Area; 340 Pound Beam Load Rating; 1418 Pound Column Load Rating
• Made In Usa: Yes
• Manufacturer: EATON B-LINE SYSTEMS INC
• Manufacturer Brand: Eaton B-Line Systems Inc.
• Sub Category: Channel/Strut
• Unspsc: 30101804
• UPC 12 Digit: 781011213305
• SKU Name: ps11001eg pstrut
