Steel City 742D 2-G Deep Floor-Box 82Cu 1/2-3/4-1-1/4" Ko

Overview

Steel City 742D 2-G Deep Floor-Box 82Cu 1/2-3/4-1-1/4" Ko

Product Specifications

• UPC: 78599111810
• Number Of Knockouts: 10
• Knockout Size: (2) 1/2 Inch Conduit Bottom, (2) 3/4 Inch Conduit Bottom, (4) 3/4 Inch Conduit Sides, (2) 1-1/4 Inch Conduit Ends
• Number Of Gangs: 2
• Service Type: Flush
• Capacity: 41 Cu Inch Each Gang
• Installation: Concrete Floor
• Device Type: Communication, Data, Power
• Cover Mounting: Carpet/Tile
• Standard Package: 1
• Approval: UL, CSA
• Catalog Number: 742D
• Model: 740
• Shape: Rectangular
• Length: 7-1/4 Inch
• Width: 5-1/2 Inch
• Depth: 3-5/8 Inch
• Adjustment Size: 2 Inch Pre-Pour, 1-1/2 Inch Post-Pour
• Material: 16 Gauge Pre-Galvanized Stamped Steel
• Catalog Description: TWO GANG DEEP FLUSH SERVICE FLOOR BOX, 82 CUBIC INCHES, LENGTH 7-1/4 INCHES, WIDTH 5-1/2 INCHES, DEPTH 3-5/8 INCHES, 1/2 INCH 3/4 INCH AND 1-1/4 INCH KNOCKOUTS, GALVANIZED STEEL, FOR POWER OR COMMUNICATIONS/DATA
• Category: Floor Boxes & Accessories
• Full Technical Description: 16 Gauge Pre-Galvanized Stamped Steel Material; 7-1/4 Inch; 5-1/2 Inch; 3-5/8 Inch; Rectangular Shape; Concrete Floor Installation; 2 Gang(S); UL, CSA Approval; 1 Standard Package; 41 Cu Inch Each Gang Capacity; Flush Service Type; (2) 1/2 Inch Conduit Bottom, (2) 3/4 Inch Conduit Bottom, (4) 3/4 Inch Conduit Sides, (2) 1-1/4 Inch Conduit Ends Knockout Size; 10 Knockout(S); Communication, Data, Power Device Type; Carpet/Tile Cover Mounting; 2 Inch Pre-Pour, 1-1/2 Inch Post-Pour Adjustment Size; MOPTITE[R] Brand; 740 Model
• Made In Usa: Yes
• Manufacturer: THOMAS & BETTS STEEL CITY/KINDORF
• Manufacturer Brand: T&B Steel City/Kindorf
• Sub Category: Floor Box
• Unspsc: 39121307
• UPC 12 Digit: 785991118100
• SKU Name: stlcity 742d
