T&B 31262 Locktite Copper Female Stud Connector 8-4

Overview

T&B 31262 Locktite Copper Female Stud Connector 8-4

Product Specifications

• UPC: 78621031262
• Approval: UL, CSA
• Additional Information: Voltage Rating 600 V
• Catalog Number: 31262
• Brand Name: LOCKTITE[R]
• Model: FL
• Minimum Conductor Size: 8 AWG
• Maximum Conductor Size: 4 AWG
• Material: Copper
• Stud Size: 3/8 Inch-16 TPI
• Size: 5/8 Inch W x 1-1/16 Inch H
• Catalog Description: LOCKTITE COPPER FEMALE STUD CONNECTOR FOR CONDUCTOR RANGE 8-4 AWG
• Category: Large Terminals & Connectors
• Full Technical Description: Copper Material; 5/8 Inch W X 1-1/16 Inch H Size; 8 AWG min. Conductor Size; 4 AWG Max. Conductor Size; UL, CSA Approval; 3/8 Inch-16 TPI Stud Size; LOCKTITE[R] Brand; Voltage Rating 600 V; FL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Mechanical Stud Connector
• Unspsc: 39121408
• UPC 12 Digit: 786210312620
• SKU Name: t&b 31262
