T&B 32003-TB Locktite Copper 2-Hole Lug 14-8 1/4B

Overview

T&B 32003-TB Locktite Copper 2-Hole Lug 14-8 1/4B

Product Specifications

• UPC: 78621032003
• Screw Type: Filister Head
• Material: Copper
• Number Of Pad Holes: 2
• Pad Size: 1-1/4 Inch L x 1/2 Inch W x 1/8 Inch Thk
• Stud Size: 1/4 Inch
• Overall Length: 1-11/16 Inch
• Approval: UL, CSA
• Catalog Number: 32003-TB
• Brand Name: LOCKTITE[R]
• Type: Long Tongue
• Number Of Conductors: 1
• Minimum Conductor Size: 14 AWG
• Maximum Conductor Size: 8 AWG
• Conductor Material: Copper
• Pad Type: Straight
• Catalog Description: LOCKTITE COPPER TWO-HOLE LUG, CONDUCTOR RANGE 14-8 AWG OR 14-4 NAVY, 1/4 INCH BOLT HOLE, FILLISTER HEAD SCREW, SCREW DRIVER TORQUE 20 IN/LBS. PAD LENGTH 1-1/4 INCH, PAD WIDTH 1/2 INCH, PAD THICKNESS 1/8 INCH. HOLES ON 5/8 INCH CENTER. OVERALL LENGTH 1-3/4 INCH. BOLT HOLE SIZE 9/32 INCH.
• Category: Large Terminals & Connectors
• Full Technical Description: Long Tongue Type; Copper Material; 1-11/16 Inch Overall Length; 14 AWG min. Conductor Size; 8 AWG Max. Conductor Size; Copper Conductor Material; UL, CSA Approval; 1 Conductor(S); 1/4 Inch Stud Size; 1-1/4 Inch L X 1/2 Inch W X 1/8 Inch Thk Pad Size; 2 Pad Hole(S); Straight Pad Type; Filister Head Screw Type; LOCKTITE[R] Brand
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Mechanical Cable Lug
• Unspsc: 39121408
• UPC 12 Digit: 786210320038
• SKU Name: t&b 32003tb
