T&B 54816 2-Way Copper Splice Connector Long Barrel 400 Blue

Overview

T&B 54816 2-Way Copper Splice Connector Long Barrel 400 Blue

Product Specifications

• UPC: 78621054816
• Outer Diameter: 0.98 Inch
• Body Material: High Conductivity Electro Tin Plated Wrought Copper
• Approval: UL, CSA
• Additional Information: Die Code 76
• Catalog Number: 54816
• Type: 2-Way
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Size: 400 KCMIL (Code), 313 KCMIL (775/24 Flex)
• Conductor Material: Copper
• Color Code: Blue
• Barrel Type: Long
• Length: 3.75 Inch
• Catalog Description: COPPER TWO-WAY SPLICE, LONG BARREL, MAX 35KV, 400 KCMIL, LENGTH 3.75 INCHES, DIAMETER 0.98 INCH, TIN PLATED, DIE CODE 76, DIE COLOR CODE BLUE
• Category: Large Terminals & Connectors
• Full Technical Description: 2-Way Type; 3.75 Inch; 0.98 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; High Conductivity Electro Tin Plated Wrought Copper Body Material; 400 kcmil (Code), 313 kcmil (775/24 Flex) Conductor Size; Blue Color Code; Long Barrel Type; Die Code 76
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 786210548166
• SKU Name: t&b 54816
