ILSCO TA-6-S 14-6 Aluminum/Copper Lug

Overview

Ilsco TA-6-S 14-6 Aluminum/Copper Lug

Product Specifications

• UPC: 78366988838
• Screw Type: Slotted
• Material: Electro Tin Plated 6061-T6 Aluminum Alloy
• Number Of Pad Holes: 1
• Pad Size: 11/16 Inch Length x 3/8 Inch Width x 3/32 Inch Thickness
• Stud Size: 1/4 Inch
• Overall Length: 1-1/16 Inch
• Approval: UL 467/486A/B, CSA
• Additional Information: RoHS Compliant; Voltage Rating 35 Kilovolt; Height 41/64 Inch; Temperature Rating 90 Deg C
• Catalog Number: TA-6-S
• Model: TA
• Type: Chamfered Wire Entry
• Number Of Conductors: 1
• Minimum Conductor Size: 14 AWG
• Maximum Conductor Size: 4 AWG
• Conductor Material: Copper/Aluminum
• Pad Type: Straight
• Catalog Description: ALUMINUM MECHANICAL LUG, CONDUCTOR RANGE 4-14, 1 PORT, 1 HOLE, 1/4IN BOLT SIZE, TIN PLATED, UL, CSA
• Category: Large Terminals & Connectors
• Full Technical Description: Chamfered Wire Entry Type; Electro Tin Plated 6061-T6 Aluminum Alloy Material; 1-1/16 Inch Overall Length; 14 AWG min. Conductor Size; 4 AWG Max. Conductor Size; Copper/Aluminum Conductor Material; UL 467/486A/B, CSA Approval; 1 Conductor(S); 1/4 Inch Stud Size; 11/16 Inch Length X 3/8 Inch Width X 3/32 Inch Thickness Pad Size; 1 Pad Hole(S); Straight Pad Type; Slotted Screw Type; RoHS Compliant; Voltage Rating 35 Kilovolt; Height 41/64 Inch; Temperature Rating 90 Deg C; TA Model
• Made In Usa: Yes
• Manufacturer: ILSCO CORP
• Manufacturer Brand: ILSCO Corp.
• Proposition 65 Warning (Ca): This product is in compliance with Prop65; it is not known to contain any chemicals associated with this regulation
• Sub Category: Mechanical Cable Lug
• Unspsc: 39121408
• UPC 12 Digit: 783669888386
• SKU Name: ta6s ilsco
