Wiegmann PB3 N4 30.5 Mm 3 Pushbutton Enclosure 8X3.2X2.7 Carbon Steel-Gray

Overview

Wiegmann PB3 N4 30.5 Mm 3 Pushbutton Enclosure 8X3.2X2.7 Carbon Steel-Gray

Product Specifications

• UPC: 78672543015
• Device Hole Size: 30.5 MM
• Material: Steel
• Material Specification: 14 Gauge
• Color: ANSI 61 Gray
• Finish: Polyester Powder Coated Over Phosphatized Surface
• Enclosure: NEMA 4/12/13
• Mounting: Wall
• Service Type: Indoor/Outdoor
• Approval: UL 508, CSA
• Additional Information: Application Pilot Light, Switch; Cover Type Screw-On; Environmental Conditions Dirt, Dust, Oil, Water
• Catalog Number: PB3
• Model: PB
• Type: Standard
• Height: 8 Inch
• Width: 3.25 Inch
• Depth: 2.81 Inch
• Number Of Device Holes: 3
• Device Hole Location: 1-Row Vertical
• Catalog Description: N4 30.5 MM 3 PUSHBUTTON ENCLOSURE 8X3.2X2.7 CARBON STEEL - GRAY
• Category: Control Station Enclosures
• Full Technical Description: Standard Type; Steel Material; Polyester Powder Coated Over Phosphatized Surface Finish; ANSI 61 Gray Color; 3.25 Inch; 8 Inch; 2.81 Inch; UL 508, CSA Approval; Wall Mounting; NEMA 4/12/13 Enclosure; 14 Gauge Material Specification; Indoor/Outdoor Service Type; 1-Row Vertical Device Hole Location; 30.5 mm Device Hole Size; 3 Device Hole(S); Application Pilot Light, Switch; Cover Type Screw-on; Environmental Conditions Dirt, Dust, Oil, Water; PB Model
• Made In Usa: Yes
• Manufacturer: WIEGMANN, E.M. &., INC.
• Manufacturer Brand: Hubbell Wiegmann
• Proposition 65 Warning (Ca): WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov
• Sub Category: Pushbutton Enclosure
• Unspsc: 39121326
• UPC 12 Digit: 786725430154
• SKU Name: wiegman pb3

Resources

• Manufacturer Spec Sheet
• Material Safety Data Sheet (MSDS)
