Ocal GUAB36SA-G Conduit Box L-Shape 1" Opening 3" Aluminum Gray

Overview

Ocal GUAB36SA-G Conduit Box L-Shape 1" Opening 3" Aluminum Gray

Product Specifications

• UPC: 70450838429
• Cover Opening Diameter: 3 INCH
• Material: ALUMINUM
• Additional Information: COLOR GRAY
• Catalog Number: GUAB36SA-G
• Brand Name: Ocal[R]
• Model: GUA
• Hub Size: 1 INCH
• Number Of Hubs: 2
• Hub Location: (1) SIDE, (1) BOTTOM
• Shape: ROUND
• Cover Type: EXTERNALLY THREADED
• Catalog Description: PVC DOUBLE-COATED CONDUIT OUTLET BOX FOR HAZARDOUS LOCATIONS, GUAB TYPE - L SHAPE, PIPE SIZE 1 INCH/27 METRIC, BOX IS ALUMINUM, COVER IS DIE CAST ALUMINUM, COVER OPENING 3.00 INCH/76.20 MILLIMETERS, GRAY
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Aluminum Material; Round Shape; 1 Inch Hub Size; 2 Hub(S); Externally Threaded Cover Type; (1) Side, (1) Bottom Hub Location; 3 Inch Cover Opening Diameter; OCAL[R] Brand; Color Gray; GUA Model
• Made In Usa: Yes
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Ocal
• Sub Category: Explosionproof Conduit Outlet Box
• Unspsc: 39121331
• UPC 12 Digit: 704508384296
• SKU Name: ocal guab36sag

Resources

• Manufacturer Spec Sheet
