Appleton AFCPT050 50Va Control Transformer

Overview

Appleton AFCPT050 50Va Control Transformer

Product Specifications

• UPC: 78138190282
• Catalog Number: AFCPT050
• Brand Name: Appleton[R]
• Type: 50 VA CONTROL POWER TRANSFORMER
• Used On: AEB SERIES MOTOR STARTER
• Constructional Feature: DUST IGNITION PROOF, EXPLOSION PROOF, WATER TIGHT
• Enclosure: CLASS I DIV 1 AND 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/4X/7B/7C/7D/9E/9F/9G
• Catalog Description: STARTER CONTROL POWER TRANSFORMER, TYPE TRANSFORMER, USED ON AELB SERIES BOLTED MOTOR STARTER, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST IGNITIONPROOF, WATERTIGHT, ENCLOSURE CLASS I DIV 1 AND 2 GROUP C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/4X/7C/7D/9E/9F/9G, POWER RATING 50 VA
• Category: Starter Accessories
• Full Technical Description: Control Power Transformer, Fused Type; Aeb Explosionproof Bolted Motor Starter Used on; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class I Zone 1 and 2 Group Iib + H2, Class III, NEMA 4/4X/7BCD/9EFG Enclosure; Explosionproof, Dust Ignitionproof, Water Tight; Power Rating 50 Volt Amp; Applicable Standard Nec/Cec
• Made In Usa: Yes
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Motor Starter Accessories
• Unspsc: 39121026
• UPC 12 Digit: 781381902823
• SKU Name: app afcpt050

Resources

• Manufacturer Spec Sheet
