Appleton AGUBSW10105A 10X10X5 Window Meter Enclosure

Overview

Appleton AGUBSW10105A 10X10X5 Window Meter Enclosure

Product Specifications

• UPC: 78138188636
• Cover Material: CORROSION RESISTANT GRAY EPOXY POWDER COATED CAST COPPER FREE ALUMINUM
• Size: 8-3/4 INCH D X 12 INCH H
• Mounting Hardware: FEET
• Enclosure: CLASS I DIV 1 AND 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/4X/7B/7C/7D/9E/9F/9G
• Approval: UL 886, CSA C22.2
• Catalog Number: AGUBSW10105A
• Brand Name: Appleton[R]
• Model: AGUB
• Constructional Feature: DUST IGNITION PROOF, EXPLOSION PROOF
• Hub Size: 4 INCH
• Cover Type: WINDOW
• Body Material: CAST COPPER FREE ALUMINUM
• Body Finish: CORROSION RESISTANT GRAY EPOXY POWDER COATED
• Catalog Description: INSTRUMENT AND METER BOX WITH COVER, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST-IGNITIONPROOF, NUMBER OF HUBS 1, HUB SIZE 3 INCH, COVER TYPE WINDOW, BODY MATERIAL COPPER-FREE ALUMINUM, BODY FINISH GRAY POWDER EPOXY COATED, COVER MATERIAL COPPER-FREE ALUMINUM, SIZE 10.63 INCH W X 5.25 INCH D X 10.63 INCH H, MOUNTING HARDWARE FEET, ENCLOSURE CLASS I DIV 1 AND 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/4X/BCD/9EFG, APPROVAL UL 886/1203, CSA C22.2, UL ( CANADA)
• Category: Meter Boxes
• Full Technical Description: 12 Inch Width X 8.75 Inch Depth X 12 Inch Height Size; 3 Inch Hub Size; UL 1203, UL (Canada and Us), CSA C22.2 Approval; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 4/4X/7BCD/9EFG Enclosure; Window Cover Type; Copper-Free Aluminum Body Material; Explosionproof, Dust Ignitionproof; Foot Mounting Hardware; Gray Epoxy Powder Coated Copper-Free Aluminum Cover Material; Gray Epoxy Powder Coated Body Finish; Inside Dimension 10.63 Inch Width X 5.25 Inch Depth X 10.63 Inch Height; Cover Opening Size 9.88 Inch; Cover Diameter 11 Inch; O-ring Material Neoprene; Application Hazardous Location; Applicable Standard Nec/Cec; AGUB Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Instrument Enclosure
• Unspsc: 39121314
• UPC 12 Digit: 781381886369
• SKU Name: app agubsw10105a

Resources

• Manufacturer Spec Sheet
