Appleton cg3138s

Overview

CG-3138S CG Series Strain Relief Straight Cord Connector, 3/8 in Trade, 5/16 to 7/16 in Cable Openings, Machined Steel, Natural

Product Specifications

• Catalog Number: CG3138S
• UPC / GTIN: 781381449311
• Manufacturer Brand: Appleton®
• UNSPSC: 39121431
• Features: Color coded identification label clearly states the catalog number and minimum/maximum cable diameter range for which the connector is designed; Neoprene sealing grommet firmly but safely grips cable jacket providing strain relief while protecting internal wiring connections against external tension on cable or cord; Steel or Teflon washer reduces friction between grommet and connector cap providing even pressure distribution, eliminating leakage resulting from grommet distortion; Large aluminum connectors 1-1/2 in thru 4 in and all steel connectors are constructed with hex head cap; For particularly harsh applications, wire mesh strain reliefs may be used with cord and cable connectors; Silicone free
• Cable Openings: 5/16 to 7/16 in
• Color: Yellow Label
• Connection Type: Threaded Hub
• Country of Origin: Mexico
• Dimensions: 0.94 in W
• Finish: Natural
• Material: Machined Steel
• Series: CG Series
• Trade Size: 3/8 in
• Type: Strain Relief
