Appleton eds1229

Overview

Appleton EDS1229 Explosion-Proof Pushbutton Station

Product Specifications

• Part Number: EDS1229
• UPC / GTIN: 78138169659
• UPC: 78138169659
• Operator Type: Front Operated Lever
• Box Type: Two Gang
• Hub Size: 1/2 Inch
• Enclosure Material: ASTM A47-77 Zinc Electroplated Dichromate Epoxy Powder Coated Malleable Iron
• Actuator Material: Nylon 6/6
• Enclosure: Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/7CD/9EFG
• Approval: UL 894/1203
• Additional Information: Application Designed to Prevent Arcing of Enclosed Switches in Ignitable Atmospheres During Connect and Disconnect Operation of Lighting and Light Power Loads, Classified Areas Where Ignitable Vapors, Gases or Highly Combustible Dusts are Present, Install
• Brand Name: Contender[R]
• Model: EDS
• Type: Dead End
• Constructional Feature: Dust Ignitionproof, Explosionproof
• Voltage Rating: 120 to 277 VAC
• Current Rating: 20 Ampere
• Contact Configuration: 1-Pole
• CATALOG DESCRIPTION: EXPLOSIONPROOF TUMBLER SWITCH CONTROL STATION, TYPE DEAD END, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST-IGNITIONPROOF, VOLTAGE RATING 120 TO 277 VAC, CURRENT RATING 20 AMPERE, CONTACT CONFIGURATION 1-POLE, OPERATOR TYPE FRONT OPERATED LEVER, BOX TYPE TWO GANG, HUB SIZE 1/2 INCH, ENCLOSURE MATERIAL ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED MALLEABLE IRON, ACTUATOR MATERIAL NYLON 6/6, ENCLOSURE CLASS I DIV 1 GROUP C D, CLASS I DIV 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 3/7CD/9EFG, APPROVAL UL 894/1203, POWER RATING 1 HP AT 120 VAC, 2 HP AT 240 VAC, APPLICATION HAZARDOUS LOCATION
• Full Technical Description: Dead End Type; 1-Pole Contact Configuration; 1/2 Inch Hub Size; Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron Enclosure Material; UL 894/1203, UL (Canada and Us), CSA C22.2 Approval; 120/277 Volt AC Voltage Rating; Class I Div 1 Group C D, Class I Div 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/7CD/9EFG Enclosure; 20 Amp Current Rating; Explosionproof, Dust Ignitionproof; Front Operated Lever Operator Type; Nylon 6/6 Actuator Material; 2-Gang Box Type; CONTENDER[TM] Brand; Power Rating 1 HP at 120 Volt AC, 2 HP at 240 Volt AC; Overall Dimension 7.41 Inch Width X 5.31 Inch Depth X 6.81 In
• Manufacturer: Appleton Electric
• Product Description: Appleton EDS1229 Explosion-Proof Pushbutton Station
• UNSPSC: 39121565
• UPC 12 Digit: 781381696593
