Appleton EFHCA-7550 1/2" Fixture Hanger

Overview

Appleton EFHCA-7550 1/2" Fixture Hanger

Product Specifications

• UPC: 78138127695
• Material: Zinc Electroplated Dichromate Epoxy Powder Coated Malleable Iron
• Approval: UL, CSA
• Additional Information: Enclosure Class I, Group A B C D, Class II Group E F G, Class III; Application Moisture, Dust and Corrosive Atmospheres are Present
• Catalog Number: EFHCA-7550
• Brand Name: Unilet[R]
• Model: EFHCA
• Fixture Type: HID, Fluorescent, Incandescent
• Fixture Stem Size: 1/2 Inch
• Conduit Size: 3/4 Inch
• Number Of Hubs: 2
• Hub Location: Side, Feed Through
• Catalog Description: LIGHTING FIXTURE CONDUIT BODY HANGER, FIXTURE TYPE HID, FLUORESCENT, INCANDESCENT, FIXTURE STEM SIZE 1/2 INCH, CONDUIT SIZE 3/4 INCH, MATERIAL ZINC ELECTROPLATE DICHROMATE EPOXY POWDER COATED MALLEABLE IRON BODY, EPOXY POWDER COATED COPPER FREE ALUMINUM COVER, APPROVAL UL 886, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST IGNITIONPROOF, ENCLOSURE TYPE CLASS I GROUP B C D, CLASS II GROUP E F G, CLASS III, OVERALL SIZE 5.69 INCH L X 5.43 INCH H, USED ON THREADED METAL CONDUIT
• Category: Lighting Accessories
• Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Epoxy Powder Coated Copper-Free Aluminum (Cover) Material; 2 Hub(S); UL 1203, CSA Approval; 350 Pound Capacity; 3/4 Inch Conduit Size; Side, Feed-Through Hub Location; HID, Fluorescent, Incandescent Fixture Type; 1/2 Inch Fixture Stem Size; UNILETS[R] Brand; Constructional Feature Explosionproof/Dust Ignitionproof; Capacity 13.8 Cubic Inch; Enclosure Rating Class I Div 1 and 2 Group A B C D, Class II Div 1 and 2 Group E F G, Class III; Application Hazardous Location; Used With Threaded Metal Conduit; Applicable Standard Nec/Cec; EFHCA Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Pendant Fixture Conduit Body Hanger
• Unspsc: 39111817
• UPC 12 Digit: 781381276955
• SKU Name: app efhca7550

Resources

• Manufacturer Spec Sheet
