Appleton GRJK-S Unilet Surface Cover

Overview

Appleton GRJK-S Unilet Surface Cover

Product Specifications

• UPC: 78138145951
• Catalog Number: GRJK-S
• Brand Name: Appleton.
• Installation: EXTERNALLY THREADED
• Cover Opening Diameter: 2.13 INCH
• Material: MALLEABLE IRON
• Enclosure: CLASS I GROUP C D, CLASS II, GROUP E F G, CLASS III
• Used On: GRJ CONDUIT OUTLET BOX
• Catalog Description: EXPLOSSIONPROOF CONDUIT OUTLET BOX COVER, TYPE SURFACE, INSTALLATION EXTERNALLY THREADED, COVER OPENING DIAMETER 2.13 INCH, MATERIAL MALLEABLE IRON, FINISH ZINC ELECTROPLATE CHROMATE EPOXY POWDER COATED, ENCLOSURE CLASS I GROUP C D, CLASS II GROUP E F G, CLASS III, USED ON GRJ SERIES CONDUIT OUTLET BOX, APPROVAL UL, CSA, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST-IGNITION PROOF
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Surface Type; Malleable Iron Material; Zinc Electroplated/Chromate/Epoxy Powder Coated Finish; Grj Conduit Outlet Box Used on; Internally Threaded Installation; UL, CSA C22.2 Approval; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; 2.13 Inch Cover Opening Diameter; UNILETS[R] Brand; Constructional Feature Explosionproof/Dust Ignitionproof; Used on Threaded Metal Conduit; Includes Internal Ground Screw; Application General Purpose Wiring, Indoor and Outdoor, Pulling of Wire, Connect Conduit Length and Change Direction of Conduit Run, Provide Access For Maintenance; Applicable Standard Nec/Cec; GRJ Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Conduit Outlet Box Cover
• Unspsc: 39121304
• UPC 12 Digit: 781381459518
• SKU Name: app grjks

Resources

• Manufacturer Spec Sheet
