Appleton ST-100FSR 1" Liquidtight Flex Connector

Overview

Appleton ST-100FSR 1" Liquidtight Flex Connector

Product Specifications

• UPC: 78138150148
• Used On: Liquidtight Flexible Metal Conduit
• Additional Information: Applicable Standard NEMA FB-1; Connector Size 1.81 Inch Dia x 1.63 Inch L; Thread Length 0.75 Inch; Application Commercial
• Catalog Number: ST-100FSR
• Model: ST
• Trade Size: 1 Inch
• Connector Type: Straight Female
• Connector Material: Zinc Electroplated Steel
• Throat Type: Non-Insulated
• Mesh Material: Stainless Steel
• Approval: UL 514B, CSA C22.2
• Catalog Description: LIQUIDTIGHT FLEXIBLE CONDUIT CONNECTOR AND WIRE MESH, TRADE SIZE 1 INCH, CONNECTOR TYPE STRAIGHT FEMALE, CONNECTOR MATERIAL ZINC ELECTROPLATED STEEL, THROAT TYPE NON-INSULATED, MESH MATERIAL STAINLESS STEEL, STANDARD PACKAGE 20, APPROVAL UL 514B, CSA C22.2, USED ON LIQUIDTIGHT FLEXIBLE METAL CONDUIT, APPLICABLE STANDARD NEMA FB-1, APPLICATION COMMERCIAL, SIZE 1.81 INCH DIA, THREAD LENGTH 0.75 INCH
• Category: Liquid Tight Flex. Conduit Fittings
• Full Technical Description: Liquid Tight Flexible Metal Conduit Used on; UL 514B, CSA C22.2 Approval; Straight Female Connector Type; 1 Inch Trade Size; Non-Insulated Throat Type; Stainless Steel Mesh Material; Zinc Electroplated Steel Connector Material; Outside Diameter 1.29 to 1.32 Inch; Enclosure Rating Class I Div 2, Class I Zone 2, Class II Div 1 and 2, Class III Div 1 and 2; Includes Threaded Hub; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1; ST-FSR Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Liquidtight Flexible Conduit Connector with Grip
• Unspsc: 39121420
• UPC 12 Digit: 781381501484
• SKU Name: app st100fsr

Resources

• Manufacturer Spec Sheet
