Appleton WSRD6352WSQ Nema12 60A Receptacle

Overview

Appleton WSRD6352WSQ Nema12 60A Receptacle

Product Specifications

• Application: For ACP6034BC Mating Plug
• Standard: UL 98, UL 50E, UL 1682, UL 1686; UL Listed: E145917, E160652; CSA Standard: C22.2 No.4, C22.2 No. 182.1; CSA Certified: 025875
• Type: Fused WSRD Series Interlocked Receptacle With Enclosure
• Voltage Rating: 600//250 VAC//VDC
• Wire Size: 6 - 2 AWG
• Brand Name: Appleton
• Material: Aluminum/Sheet Metal
• Mounting: Surface Mount
• Nema Rating: NEMA 3R, 12
• Number Of Poles: 4
• Number Of Wires: 3
• Phase: 3
• Special Features: With viewing window; With enclosed disconnect switch; For use where an interlocked disconnect switch is desired to control a Powertite receptacle and insertion or removal of plug; For use where an interlocked disconnect switch is desired to control a Powertite receptacle and insertion or removal of plug; Utilizes style 2 (shell and extra pole) grounding and 3-wire, 4-pole receptacle wiring; Class R fusing standard on WSRD fusible units; Short circuit withstand rated to 200000 RMS symmetrical Amps; Unit is equipped with defeatable door interlock which allows emergency access when switch is energized; Cover can be padlocked closed; Dead front design: receptacle is not energized until plug is fully inserted and switch is engaged; For welders, generators, compressors, infrared ovens, batch feeders, conveyors, truck terminals, marine docks
• Catalog Description: APPLETON FUSED WSRD SERIES INTERLOCKED RECEPTACLE WITH ENCLOSURE, NUMBER OF POLES: 4, NUMBER OF WIRES: 3, WIRE SIZE: 6 - 2 AWG, AMPERAGE RATING: 60 AMP, VOLTAGE RATING: 600 VAC AT 50/60 HZ, 250 VDC, PHASE: 3 PH, MATERIAL: COPPERFREE (4/10 OF 1 PCT MAXIMUM) ALUMINUM RECEPTACLE, SHEET METAL ENCLOSURE, NEMA RATING: NEMA 3R, 12, MOUNTING: SURFACE MOUNT, MOTOR HORSEPOWER: 15 HP STANDARD/50 HP MAXIMUM AT 600 VAC, FINISH: EPOXY POWDER COAT RECEPTACLE, ENAMEL COATED ENCLOSURE, DIMENSIONS: 10.81 IN WIDTH X 23 IN HEIGHT X 10 IN DEPTH, STANDARD: UL 98, UL 50E, UL 1682, UL 1686, UL LISTED: E145917, E160652, CSA STANDARD: C22.2 NO.4, C22.2 NO. 182.1, CSA CERTIFIED: 025875, FOR ACP6034BC MATING PLUG
• Category: Pin & Sleeve Devices
• Full Technical Description: Interlocked Type; Epoxy Powder Coated Copper-Free Aluminum (Receptacle), Enamel Coated Sheet Metal (Enclosure) Material; 3 Wire(S); 600 Volt AC 50/60 Hertz 3-Phase, 250 Volt DC Voltage Rating; NEMA 3/12 Enclosure; 60 Amp Current Rating; 4 Pole(S); Rain Tight, Water Tight; Fusible Fuse Provision; Spring, Padlockable Cover; 2, Shell, Extra Pole Ground
• Made In Usa: Yes
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Pin and Sleeve Receptacle with Disconnect
• Unspsc: 39121406
• UPC 12 Digit: 781381756990
• SKU Name: app wsrd6352wsq
