Appleton BC300-M 3" Malleable C Mogul Unilet (Body, Cover & Gasket)

Overview

Appleton BC300-M 3" Malleable C Mogul Unilet (Body, Cover & Gasket)

Product Specifications

• UPC: 78138147416
• Size: 26.88 Inch Length x 4.63 Inch Width x 5.94 Inch Height
• Installation: Threaded
• Material: Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron Body, Stainless Steel Cover Screw, Neoprene Gasket
• Approval: UL 514B, CSA C22.2
• Used On: IMC/Rigid Conduit
• Additional Information: FEDERAL SPECIFICATION W-C-586B
• Catalog Number: BC300-M
• Brand Name: Unilet[R]
• Access Opening: Side
• Configuration: C
• Cover Type: Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron
• Hub Location: Straight
• Number Of Hubs: 2
• Hub Size: 3 Inch
• Catalog Description: MOGUL UNILETS TYPE C NEC 8X CONDUIT OUTLET BODY WITH ASSEMBLED COVER AND GASKET, HUB SIZE: 3 IN, LENGTH: 26.88 IN, WIDTH: 4.63 IN, HEIGHT: 5.94 IN, MATERIAL: MALLEABLE IRON, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDE
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Screw) Material; 26.88 Inch Length X 4.63 Inch Width X 5.94 Inch Height Size; Imc/Threaded Rigid Metal Conduit Used on; 3 Inch Hub Size; Threaded Installation; C Configuration; 2 Hub(S); UL 514B, CSA C22.2 Approval; Straight Hub Location; Side Access Opening; UNILETS[R] Brand; Wire Size (3) 700 MCM; Capacity 475 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381474160
• SKU Name: appleton bc300m

Resources

• Manufacturer Spec Sheet
