Appleton es500400

Overview

Appleton ES500400 4" Sealing Hub

Product Specifications

• Part Number: ES500400
• UPC / GTIN: 78138170327
• UPC: 78138170327
• Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron
• Approval: UL 886, CSA C22.2
• Used On: Threaded Rigid Metal Conduit/IMC
• Additional Information: Internal Volume 91.23 Inch; Enclosure Class I Div 1 and 2 Group A B C D, Class II Div 1 and 2 Group E F G, Class III
• Brand Name: Unilet[R]
• Model: ES
• Type: Tapered Male/Female Threaded
• Throat Type: Non-Insulated
• Trade Size: 5 Inch (Male Hub), 4 Inch (Female Hub)
• Size: 6.63 Inch Dia x 7 Inch L
• Ground Type: Grounding
• CATALOG DESCRIPTION: APPLETON UNILETS SEALING HUB, SIZE: 4 X 5 IN, MATERIAL: MALLEABLE IRON, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), CONNECTION: TAPERED MNPT X TAPERED FNPT, CUBIC CAPACITY: 91.23 CU-IN, LENGTH: 7 IN, HEIGHT: 6.63 IN, STANDARD: UL 886 (1203), UL FILE NUMBER E10444, CSA C22.2 NO. 30, CSA 065181, UL LISTED FOR CLASS I, GROUPS B, C, D, CLASS II, GROUPS E, F, G, AND CLASS III, FOR USE WITH THREADED RIGID METAL CONDUIT AND IMC
• Full Technical Description: Tapered Male/Female Threaded Type; Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron Material; 6.63 Inch Diameter X 7 Inch Length Size; Imc/Threaded Rigid Conduit Used on; UL 886, CSA C22.2 Approval; Grounding; 5 Inch (Male Hub), 4 Inch (Female Hub) Trade Size; Explosionproof, Dust Ignitionproof; UNILETS[R] Brand; Internal Volume 91.23 Cubic Inch; Enclosure Rating Class I Division 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III; Application Switch Gear, Motor Control Center, Sheet Metal Structure, Cast Box, Enclosure; Applicable Standard Nec/Cec; ES Model
• Manufacturer: Appleton Electric
• Product Description: Appleton ES500400 4" Sealing Hub
• UNSPSC: 39121311
• UPC 12 Digit: 781381703277
