Appleton es600500

Overview

Appleton ES600500 5" Sealing Hub

Product Specifications

• Catalog Number: ES600500
• UPC / GTIN: 78138170328
• Brand Name: Appleton
• Type: Sealing Hub
• Connection: Tapered MNPT X Tapered FNPT
• Cubic Capacity: 143.73 CU-IN
• Finish: Zinc Electroplate/Chromate/Epoxy Powder Coat
• Material: Malleable Iron
• Size: 5 X 6 IN
• Special Features: Explosionproof, dust-ignitionproof; Smooth, rounded integral bushing in each hub protects conductor insulation; Accurately tapped, tapered threads for tight, rigid joints and ground continuity; Allows up to 25 PCT conduit fill in compliance with the National Electrical Code; Can be used as a male thread enlarger or conduit hub in an ordinary location; UL listed for use with Kwiko A sealing compound, also listed with certain competitors sealing cement, contact factory for details; Kwiko A cement required: 1 OZ/GM; Used to seal vertical conduit risers at switch gear and motor control centers, sheet metal structures or cast boxes and enclosures
• Standard: UL 886 (1203), UL File Number E10444, CSA C22.2 No. 30, CSA 065181
• Sub Brand: UNILETS
• CATALOG DESCRIPTION: UNILETS SEALING HUB, SIZE: 5 X 6 IN, MATERIAL: MALLEABLE IRON, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), CONNECTION: TAPERED MNPT X TAPERED FNPT, CUBIC CAPACITY: 143.73 CU-IN, LENGTH: 7-1/2 IN, HEIGHT: 7.63 IN, STANDARD: UL 886 (1203), UL FILE NUMBER E10444, CSA C22.2 NO. 30, CSA 065181, FOR USE WITH THREADED RIGID METAL CONDUIT AND IMC
• Full Technical Description: Tapered Male/Female Threaded Type; Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron Material; 7.63 Inch Diameter X 7.5 Inch Length Size; Imc/Threaded Rigid Conduit Used on; UL 886, CSA C22.2 Approval; Grounding; 6 Inch (Male Hub), 5 Inch (Female Hub) Trade Size; Explosionproof, Dust Ignitionproof; UNILETS[R] Brand; Internal Volume 143.73 Cubic Inch; Enclosure Rating Class I Division 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III; Application Switch Gear, Motor Control Center, Sheet Metal Structure, Cast Box, Enclosure; Applicable Standard Nec/Cec; ES Model
• Manufacturer: Appleton Electric
• Product Description: Appleton ES600500 5" Sealing Hub
• UNSPSC: 39121311
• UPC 12 Digit: 781381703284
