Appleton jbk75a

Overview

Appleton JBK75A 3/4" Hub Cover

Product Specifications

• Part Number: JBK75A
• UPC / GTIN: 78138171229
• UPC: 78138171229
• Brand Name: Unilet[R]
• Type: Hub
• Opening Type: (1) 3/4 Inch Hub
• Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron
• Mounting: Screw
• Approval: UL 514A
• Additional Information: Includes Screw; Applicable Standard NEMA FB-1; Used On Rigid Metal Conduit/IMC
• CATALOG DESCRIPTION: CAST COVER, MATERIAL: COPPERFREE (4/10 OF 1 PCT MAXIMUM) ALUMINUM, FINISH: EPOXY POWDER COAT, SIZE: 3/4 IN HUB, NUMBER OF OUTLET: (1) HUB, MOUNTING: BOX, DEPTH: 0.94 IN, FOR USE WITH UNILETS JB CONDUIT OUTLET BOXES
• Full Technical Description: Epoxy Powder Coated Aluminum Material; UL 514A Approval; (1) 3/4 Inch Hub Opening Type; Depth 0.94 Inch; Enclosure Rating FB-1; Includes Screw; Used on Imc/Rigid Metal Conduit; Applicable Standard NEC
• Manufacturer: Appleton Electric
• Product Description: Appleton JBK75A 3/4" Hub Cover
• UNSPSC: 39121304
• UPC 12 Digit: 781381712293
