Appleton ws100aux1

Overview

Appleton WS100AUX1 100A 1N0/Inc Auxillary Contact

Product Specifications

• Part Number: WS100AUX1
• UPC / GTIN: 78138171829
• UPC: 78138171829
• Switch Type: DISCONNECT
• Additional Information: 1 NORMALLY OPENED AND 1 NORMALLY CLOSED CONTACT; FOR 30 AMPERE PLUG
• CATALOG DESCRIPTION: INTERLOCKED SWITCHED RECEPTACLE AUXILIARY CONTACT, TYPE FUSED AUXILIARY CONTACT, USED ON IBR SERIES INTERLOCKED SWITCHED RECEPTACLE, PHASE 3, POWER RATING 30/70 HP AT 600 VAC, CURRENT RATING 100 AMPERE, APPLICATION AUTOMOTIVE AND STEEL PROCESSING PLANT, PULP AND PAPER PROCESSING PLANT, MILK PROCESSING PLANT AND CREAMERY, FABRICATION YARDS AND SHIPYARD, REFRIGERATED TRUCK TERMINAL MOTOR GENERATOR UNIT, WELDER, PUMP
• Full Technical Description: Interlocked Type; Epoxy Powder Coated Copper-Free Aluminum Material; 3 Wire(S); 600 Volt AC 3-Phase Voltage Rating; NEMA 3/4X/5 Enclosure; 100 Amp Current Rating; 3 Pole(S); Weatherproof, Water Tight; Fusible Fuse Provision; Spring; 2 Grounding Style; Switching Configuration 1NO-NC; Application Chemical/Process Facility/Meat Packing Plant; Applicable Standard NEC
• Manufacturer: Appleton Electric
• Product Description: Appleton WS100AUX1 100A 1N0/Inc Auxillary Contact
• UNSPSC: 39121406
• UPC 12 Digit: 781381718295
