Blackburn ASP750 750 Aluminum Test Point Splice Sleeve 5-3/8"

Overview

Blackburn ASP750 750 Aluminum Test Point Splice Sleeve 5-3/8"

Product Specifications

• UPC: 78378661075
• Approval: UL, CSA
• Additional Information: Constructional Feature Corrosion Resistance
• Catalog Number: ASP750
• Model: ASP
• Voltage Rating: 35 KV
• Conductor Size: 750 KCMIL
• Conductor Material: Aluminum/Copper
• Barrel Type: Standard with Chamfered End
• Length: 5-3/8 Inch
• Body Material: Seamless Tin Plated High Conductivity Aluminum
• Catalog Description: TYPE ASP ALUMINUM SPLICE, MAX 35KV, 750 KCMIL, LENGTH 5-3/8 INCH, TIN PLATED, DIE COLOR CODE N/A
• Category: Large Terminals & Connectors
• Full Technical Description: 5-3/8 Inch; Aluminum/Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; Seamless Tin Plated High Conductivity Aluminum Body Material; 750 kcmil Conductor Size; Standard With Chamfered End Barrel Type; Constructional Feature Corrosion Resistance; ASP Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 783786610754
• SKU Name: asp750 blkbrn
