B-Line B435HDG Beam ClAMP, 2-1/8" Max Flange, Hd Galvanized

Overview

B-Line B435HDG Beam Clamp, 2-1/8" Max Flange, Hd Galvanized

Product Specifications

• UPC: 78101155115
• Material: Carbon Steel
• Material Specification: ASTM A123
• Finish: Hot Dip Galvanized
• Application: Channel
• Additional Information: Overall Dimension 2 Inch L x 1-1/4 Inch W x 2-7/8 Inch H
• Catalog Number: B435HDG
• Model: B435
• Type: I
• Maximum Jaw Capacity: 2-1/8 Inch
• Supplied With Screw: Yes
• Screw Type: Square Head
• Screw Size: 1/2 Inch-13 TPI
• Load Capacity: 1000 Lb
• Catalog Description: EATON B-LINE SERIES BEAM CLAMPS, 900 LB, STEEL, SAFETY FACTOR OF 5, BEAM CLAMP, 1/2"-13 THREAD/ROD SIZE, 1/2" SCREW SIZE, 2/8" BEAM THICKNESS, HOT-DIPPED GALVANIZED
• Category: Channel & Strut Fittings
• Full Technical Description: I Type; Carbon Steel Material; Hot Dip Galvanized Finish; 2-1/8 Inch Max. Jaw Capacity; Channel Application; ASTM A123 Material Specification; 1000 lb Load Capacity; 1/2 Inch-13 TPI Screw Size; Square Head Screw Type; Yes Supplied With Screw; Overall Dimension 2 Inch L X 1-1/4 Inch W X 2-7/8 Inch H; B435 Model
• Made In Usa: Yes
• Manufacturer: Eaton B-Line
• Manufacturer Brand: Eaton B-Line Systems Inc.
• Sub Category: Beam Clamp
• Unspsc: 30101804
• UPC 12 Digit: 781011551155
• SKU Name: bline b435hdg
