Burndy BIBS-600-5 Multiple Wire Terminal

Overview

Burndy BIBS-600-5 Multiple Wire Terminal

Product Specifications

• Catalog Description: CLEAR PLASTISOL COVERED, SINGLE SIDE ENTRY, 5 PORTS, #4 AWG-600 KCMIL. AL/CU RATED. OXIDE INHIBITOR IS PRE-INSTALLED.
• Category: Large Terminals & Connectors
• Full Technical Description: 4 AWG (Aluminum), 4 AWG Stranded (Copper) min. Conductor Size; 600 kcmil (Aluminum), 600 kcmil Stranded (Copper) Max. Conductor Size; Aluminum/Copper Conductor Material; UL 486B, CSA Approval; 600 V Voltage Rating; Clear Plastisol Covered AL6061-T6 Aluminum Body Material; 5 Port(S); 1 Side Entry Cable Entry; UNITAP[TM] Brand; RoHS Compatible; Temperature Rating 90 Deg C; Size 6.56 Inch L X 2.38 Inch W X 2.75 Inch H; Hex Key Size 3/8 Inch; Number of Screw 5; BIBS Model
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Sub Category: Mechanical Multiple Cable Tap
• Unspsc: 39121427
• UPC 12 Digit: 781810224120
• SKU Name: bur bibs6005

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
