Burndy Y3431R 500-350 Copper Red Adapter

Overview

Burndy Y3431R 500-350 Copper Red Adapter

Product Specifications

• UPC: 78181000110
• Outer Diameter: 0.821 Inch
• Length: 2.5 Inch
• Material: High Conductivity Electrolytic Tin Plated Copper
• Additional Information: RoHS Compatible
• Catalog Number: Y3431R
• Brand Name: HYLINK[TM]
• Model: Y-R
• Type: Reducing Adapter
• Voltage Rating: 600 V to 35 KV
• Conductor Material: Copper
• Side A Conductor Size: 500 KCMIL
• Side B Conductor Size: 350 KCMIL
• Catalog Description: 500 KCMIL CU LONG BARREL SIZE REDUCED DOWN TO 350 KCMIL WIRE SIZE, INTERNAL CHAMFER, TIN PLATED, UP TO 35KV, BROWN COLOR CODE, 20 OR 299 DIE INDEX.
• Category: Small Terminals & Connectors
• Full Technical Description: Reducing Adapter Type; High Conductivity Electrolytic Tin Plated Copper Material; 2.5 Inch; 0.821 Inch Outer Diameter; Copper Conductor Material; 600 V to 35 kV Voltage Rating; 350 kcmil Side B Conductor Size; 500 kcmil Side A Conductor Size; RoHS Compatible; Y-R Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Reducer
• Unspsc: 39121458
• UPC 12 Digit: 781810001103
• SKU Name: bur y3431r

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
