Burndy Y3432R 500-400 Copper Red Adapter

Overview

Burndy Y3432R 500-400 Copper Red Adapter

Product Specifications

• UPC: 78181000111
• Length: 1.12 INCH
• Length In Inch: 1.12
• Body Material: PENETROX[T] OXIDE INHIBITING COMPOUND PREFILLED ELECTRO TIN PLATED ALUMINUM
• Approval: UL
• Length In Inch Uom: in
• Additional Information: APPLICABLE STANDARD IEEE 323, IEEE 344, IEEE 383, NEC; WIRE STRIP LENGTH 5/8 INCH
• Catalog Number: Y3432R
• Brand Name: HYLINK[T]
• Model: YS-A
• Type: BUTT WITH SOLID CENTER STOP
• Voltage Rating: 600 V TO 35 KV
• Conductor Size: 10 AWG SOLID
• Conductor Material: ALUMINUM/COPPER
• Barrel Type: STANDARD WITH BELLED END
• Catalog Description: 500 KCMIL CU LONG BARREL SIZE REDUCED DOWN TO 400 KCMIL WIRE SIZE, INTERNAL CHAMFER, TIN PLATED, UP TO 35KV, BROWN COLOR CODE, 20 OR 299 DIE INDEX.
• Category: Small Terminals & Connectors
• Full Technical Description: Butt With Solid Center Stop Type; 1.12 Inch; 1.12 Length in Inch; Aluminum/Copper Conductor Material; UL Approval; 600 V to 35 kV Voltage Rating; PENETROX[T] Oxide Inhibiting Compound Prefilled Electro Tin Plated Aluminum Body Material; 10 AWG Solid Conductor Size; Standard With Belled End Barrel Type; HYLINK[T] Brand; Applicable Standard IEEE 323, IEEE 344, IEEE 383, NEC; Wire Strip Length 5/8 Inch; Length in Inch - Uom in; YS-A Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Splice
• Unspsc: 39121458
• UPC 12 Digit: 781810001110
• SKU Name: bur y3432r

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
