Burndy Y3934R 750-500 Copper Red Adapter

Overview

Burndy Y3934R 750-500 Copper Red Adapter

Product Specifications

• UPC: 78181000112
• Outer Diameter: 1.02 Inch
• Length: 2.88 Inch
• Material: High Conductivity Electrolytic Tin Plated Copper
• Approval: UL, CSA
• Additional Information: RoHS Compatible
• Catalog Number: Y3934R
• Brand Name: HYLINK[TM]
• Model: Y-R
• Type: Reducing Adapter
• Voltage Rating: 600 V to 35 KV
• Conductor Material: Copper
• Side A Conductor Size: 750 KCMIL
• Side B Conductor Size: 500 KCMIL
• Catalog Description: 750 KCMIL CU LONG BARREL SIZE REDUCED DOWN TO 500 KCMIL WIRE SIZE, INTERNAL CHAMFER, TIN PLATED, UP TO 35KV, BLACK COLOR CODE, 24 DIE INDEX.
• Category: Hand Tool Bits, Parts, Accessories
• Full Technical Description: Reducing Adapter Type; High Conductivity Electrolytic Tin Plated Copper Material; 2.88 Inch; 1.02 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 500 kcmil Side B Conductor Size; 750 kcmil Side A Conductor Size; RoHS Compatible; Y-R Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Reducer
• Unspsc: 39121458
• UPC 12 Digit: 781810001127
• SKU Name: bur y3934r

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
