Burndy YA34-TC12-FXB 2-Hole Copper Lug

Overview

Burndy YA34-TC12-FXB 2-Hole Copper Lug

Product Specifications

• UPC: 78181003988
• Pad Size: 1.55 Inch W x 0.23 Inch Thk
• Number Of Pad Holes: 1
• Stud Size: 1/2 Inch
• Color: Blue
• Die Index: 19
• Material: Electro-Tin Plated Copper
• Overall Length: 4.54 Inch
• Approval: UL 468A/468B, CSA
• Additional Information: RoHS Compatible; Temperature Rating 90 Deg C; Wire Strip Length 2-9/16 Inch
• Catalog Number: YA34TC12FXB
• Brand Name: HYLUG[TM]
• Model: YAV-TC-FXB
• Voltage Rating: 600 V to 35 kV
• Conductor Material: Copper
• Conductor Size: 925/24 Diesel Locomotive Cable, 373.7 KCMIL Class G/H/I/M (Flex), 400 KCMIL Stranded
• Barrel Type: Long, Belled, Standard, Straight
• Barrel Length: 2.48 Inch
• Catalog Description: 350 KCMIL G,H,I,K,M,373 DLO CU, ONE HOLE, 1/2 STUD SIZE, LONG BARREL, BELL END, TIN PLATED, UL/CSA, 90C, UP TO 35KV, BLUE COLOR CODE, 19 DIE INDEX.
• Category: Large Terminals & Connectors
• Full Technical Description: Electro-Tin Plated Copper Material; Blue Color; 4.54 Inch Overall Length; 2.48 Inch Barrel Length; Copper Conductor Material; UL 468A/468B, CSA Approval; 600 V to 35 kV Voltage Rating; 925/24 Diesel Locomotive Cable, 373.7 kcmil Class G/H/I/M (Flex), 400 kcmil Stranded Conductor Size; 1/2 Inch Stud Size; 19 Die Index; 1.55 Inch W X 0.23 Inch Thk Pad Size; 1 Pad Hole(S); Long, Belled, Standard, Straight Barrel Type; HYLUG[TM] Brand; RoHS Compatible; Temperature Rating 90 Deg C; Wire Strip Length 2-9/16 Inch; YAV-TC-FXB Model
• Made In Usa: Yes
• Manufacturer: BURNDY PRODUCTS
• Manufacturer Brand: Burndy Products
• Product Brochure: h
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810039885
• SKU Name: bur ya34tc12fxb

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
