Burndy YAEV8CLBOX 8Awg Nylon Ring

Overview

Burndy YAEV8CLBOX 8Awg Nylon Ring

Product Specifications

• UPC: 78181056500
• Temperature Rating: 105 Deg C
• Approval: UL
• Additional Information: RoHS Compatible; Dimension 1.4 Inch L x 0.41 Inch W; Material Electrolytic Tin Plated Copper; Wire Strip Length 7/16 Inch; Maximum Insulation Diameter 0.258 Inch
• Catalog Number: YAEV8CLBOX
• Brand Name: INSULUG[TM]
• Model: YAEV-L
• Type: Seamless Barrel, Double Thick Tongue
• Maximum Conductor Size: 8 AWG Stranded (Copper), 8 AWG (Aircraft)
• Color: Red
• Insulation Type: Nylon Insulated
• Stud Size: #10
• Catalog Description: COPPER TUBING TERMINAL, 10, 1.397 IN L, .407 IN W, 600 VOLTS MAX.
• Category: Large Terminals & Connectors
• Full Technical Description: Seamless Barrel, Double Thick Tongue Type; Red Color; 8 AWG Stranded (Copper), 8 AWG (Aircraft) Max. Conductor Size; UL Approval; 105 Deg C Temperature Rating; #10 Stud Size; Nylon Insulated Insulation Type; INSULUG[TM] Brand; RoHS Compatible; Dimension 1.4 Inch L X 0.41 Inch W; Material Electrolytic Tin Plated Copper; Wire Strip Length 7/16 Inch; Maximum Insulation Diameter 0.258 Inch; YAEV-L Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Sub Category: Ring Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810565001
• SKU Name: bur yaev8clbox
