Burndy YAZ26-TC12 1-Hole Compression Lug

Overview

Burndy YAZ26-TC12 1-Hole Compression Lug

Product Specifications

• UPC: 78181024003
• Pad Size: 0.83 INCH W X 0.12 INCH THK
• Number Of Pad Holes: 1
• Stud Size: 1/2 INCH
• Color: BLACK
• Die Index: 13
• Material: ELECTRO TIN PLATED COPPER
• Overall Length: 3 INCH
• Approval: UL, CSA
• Additional Information: ROHS COMPATIBLE; CABLE ENTRY TYPE BEVELED, CHAMFERED; WIRE STRIP LENGTH 1 9/16 INCH; TEMPERATURE RATING 90 DEG C; WITH INSPECTION WINDOW
• Catalog Number: YAZ26TC12
• Brand Name: HYLUG[T], BURNDY[R]
• Model: YAZ
• Voltage Rating: 600 V TO 35 KV
• Conductor Material: COPPER
• Conductor Size: 2/0 AWG STRANDED, 125 NAVY
• Barrel Type: LONG, SKIVED, STRAIGHT
• Barrel Length: 1.5 INCH
• Catalog Description: 2/0 AWG CU, ONE HOLE, 1/2 STUD SIZE, LONG BARREL, INSPECTION WINDOW, INTERNAL CHAMFER, TIN PLATED, UL/CSA, 90C, UP TO 35KV, BLACK COLOR CODE, 13 DIE INDEX.
• Category: Large Terminals & Connectors
• Full Technical Description: Copper Material; Black Color; 3 Inch Overall Length; 1.5 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 600 to 35000 Volt Voltage Rating; 125 (Navy), 2/0 AWG Conductor Size; 1/2 Inch Stud Size; 13 Die Index; 0.83 Inch Pad Size; 1 Pad Hole(S); Long Barrel Type; HYLUG[TM] Brand; Type Terminal; Plating Type Tin; Barrel Style Chamfered, Skived; Tongue Angle Straight; Application Code Conductor
• Made In Usa: Yes
• Manufacturer: BURNDY PRODUCTS
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810240038
• SKU Name: bur yaz26tc12
