Burndy YHD-3 1/0-2/0R 6-2T Aluminum H Tap

Overview

Burndy YHD-3 1/0-2/0R 6-2T Aluminum H Tap

Product Specifications

• UPC: 78181013906
• Minimum Tap Conductor Size: 6 AWG (ACSR), 6 AWG (Copper/Aluminum/ACSR, Compact), 6 AWG Solid/Stranded
• Maximum Tap Conductor Size: 2 AWG (ACSR), 1 AWG (Copper/Aluminum/ACSR, Compact), 1 AWG Stranded, 1/0 AWG Solid
• Die Index: D3
• Body Material: Aluminum
• Approval: CSA
• Additional Information: RoHS Compatible; Size 1.88 Inch L x 0.76 Inch W x 1.47 Inch H
• Catalog Number: YHD3
• Brand Name: LOKTAP[TM]
• Model: YHD
• Shape: H
• Number Of Taps: 1
• Conductor Material: Copper/Aluminum/ACSR
• Minimum Run Conductor Size: 1/0 AWG (ACSR), 2/0 AWG (ACSR, Compact), 2/0 AWG Stranded, 3/0 AWG (Copper/Aluminum, Compact), 3/0 AWG Solid
• Maximum Run Conductor Size: 2/0 AWG (ACSR), 3/0 AWG (Copper/Aluminum/ACSR, Compact), 3/0 AWG Stranded, 4/0 AWG Solid
• Catalog Description: COMPRESSION LINE TAP CONNECTOR FOR ALUMMINUM TO COPPER AND ALUMINUM TO ALUMINUM APPLICATIONS,1.47 H,1.88 L,.76 W.
• Category: Large Terminals & Connectors
• Full Technical Description: 1/0 AWG (ACSR), 2/0 AWG (ACSR, Compact), 2/0 AWG Stranded, 3/0 AWG (Copper/Aluminum, Compact), 3/0 AWG Solid min. Run Conductor Size; 2/0 AWG (ACSR), 3/0 AWG (Copper/Aluminum/Acsr, Compact), 3/0 AWG Stranded, 4/0 AWG Solid Max. Run Conductor Size; 6 AWG (ACSR), 6 AWG (Copper/Aluminum/Acsr, Compact), 6 AWG Solid/Stranded min. Tap Conductor Size; 2 AWG (ACSR), 1 AWG (Copper/Aluminum/Acsr, Compact), 1 AWG Stranded, 1/0 AWG Solid Max. Tap Conductor Size; H Shape; Copper/Aluminum/Acsr Conductor Material; CSA Approval; Aluminum Body Material; D3 Die Index; 1 Tap(S); LOKTAP[TM] Brand; RoHS Compatible; Size 1.88 Inch L X 0.76 Inch W X 1.47 Inch H; YHD Model
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Sub Category: Compression Cable Tap
• Unspsc: 39121427
• UPC 12 Digit: 781810139066
• SKU Name: bur yhd3

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
