Burndy YHD-7 4/0 Aluminum/Copper Tap Connector

Overview

Burndy YHD-7 4/0 Aluminum/Copper Tap Connector

Product Specifications

• UPC: 78181013916
• Minimum Tap Conductor Size: 3/0 AWG (ACSR), 3/0 AWG (ACSR, Compact), 3/0 AWG Stranded, 4/0 AWG (Copper/Aluminum, Compact), 250 KCMIL Solid
• Maximum Tap Conductor Size: 4/0 AWG (ACSR), 4/0 AWG Stranded, 266 KCMIL (Copper/Aluminum/ACSR, Compact), 300 KCMIL Solid
• Die Index: D3
• Body Material: Aluminum
• Approval: CSA
• Additional Information: RoHS Compatible; Size 2.52 Inch L x 0.83 Inch W x 1.42 Inch H
• Catalog Number: YHD7
• Brand Name: LOKTAP[TM]
• Model: YHD
• Shape: H
• Number Of Taps: 1
• Conductor Material: Copper/Aluminum/ACSR
• Minimum Run Conductor Size: 3/0 AWG (ACSR), 3/0 AWG (ACSR, Compact), 3/0 AWG Stranded, 4/0 AWG (Copper/Aluminum, Compact), 250 KCMIL Solid
• Maximum Run Conductor Size: 4/0 AWG (ACSR), 4/0 AWG Stranded, 266 KCMIL (Copper/Aluminum/ACSR, Compact), 300 KCMIL Solid
• Catalog Description: COMPRESSION LINE TAP CONNECTOR FOR ALUMMINUM TO COPPER AND ALUMINUM TO ALUMINUM APPLICATIONS,1.40 H,2.52 L,.84 W.
• Category: Large Terminals & Connectors
• Full Technical Description: 3/0 AWG (ACSR), 3/0 AWG (ACSR, Compact), 3/0 AWG Stranded, 4/0 AWG (Copper/Aluminum, Compact), 250 kcmil Solid min. Run Conductor Size; 4/0 AWG (ACSR), 4/0 AWG Stranded, 266 kcmil (Copper/Aluminum/Acsr, Compact), 300 kcmil Solid Max. Run Conductor Size; 3/0 AWG (ACSR), 3/0 AWG (ACSR, Compact), 3/0 AWG Stranded, 4/0 AWG (Copper/Aluminum, Compact), 250 kcmil Solid min. Tap Conductor Size; 4/0 AWG (ACSR), 4/0 AWG Stranded, 266 kcmil (Copper/Aluminum/Acsr, Compact), 300 kcmil Solid Max. Tap Conductor Size; H Shape; Copper/Aluminum/Acsr Conductor Material; CSA Approval; Aluminum Body Material; D3 Die Index; 1 Tap(S); LOKTAP[TM] Brand; RoHS Compatible; Size 2.52 Inch L X 0.83 Inch W X 1.42 Inch H; YHD Model
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Sub Category: Compression Cable Tap
• Unspsc: 39121427
• UPC 12 Digit: 781810139165
• SKU Name: bur yhd7

Resources

• Technical Drawing
• Technical Line Drawing
• Manufacturer Spec Sheet
