Burndy YS36-L 600Mcm Butt Splice

Overview

Burndy YS36-L 600Mcm Butt Splice

Product Specifications

• UPC: 78181052640
• Barrel Type: Standard with Chamfered End
• Length: 3.22 Inch
• Body Material: Electro Tin Plated Copper
• Approval: UL 468A/468B, CSA
• Additional Information: ROHS COMPATIBLE; WIRE STRIP LENGTH 1 7/16 INCH; DIE INDEX 22 OR 472; TEMPERATURE RATING 90 DEG C; APPLICATION LIMITED SPACE
• Catalog Number: YS36L
• Brand Name: HYLINK[TM]
• Model: YS-L
• Type: Butt
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Size: 600 KCMIL (Code)
• Conductor Material: Copper
• Color Code: Green
• Catalog Description: 600 KCMIL CU, STANDARD BARREL, INTERNAL CHAMFER, TIN PLATED, UL/CSA, 90C, UP TO 35KV, GREEN COLOR CODE, 22 OR 472 DIE INDEX.
• Category: Large Terminals & Connectors
• Full Technical Description: Butt Type; 3.22 Inch; Copper Conductor Material; UL 468A/468B, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; Electro Tin Plated Copper Body Material; 600 kcmil (Code) Conductor Size; Green Color Code; Standard With Chamfered End Barrel Type; HYLINK[TM] Brand; RoHS Compatible; Wire Strip Length 1 7/16 Inch; Die Index 22 or 472; Temperature Rating 90 Deg C; Application Limited Space; YS-L Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 781810526408
• SKU Name: bur ys36l
