Burndy y3429r

Overview

Y3429R, Compression Splice Reducer, Barrel A 500 kcmil, Barrel B 250 kcmil

Product Specifications

• Part Number: Y3429R
• UPC / GTIN: 781810001080
• Manufacturer Brand: Burndy
• Application: Wire Reducing Splice Adapter Insert
• Color Code: Brown
• Connector Type: LONG BARREL
• Die Index: 20
• EU RoHS Indicator:
• Feature - Barrel Type: Long
• Finish Type: Tin-Plated
• Material: COPPER
• Plated: Y
• Plating Type: Tin - Electro Plated
• Sub Brand: REDUCER/ADAPTER
• Temperature Rating: 194
• Type: Y-R, Compression
• UPC: 781810001080
• UPC 14 Digit GTIN: 00781810001080
• Dimension - B Length inch: 2.50 in
• Dimension - L Length Overall mm: 64 mm
• Dimension - Length Overall inch: 2.50 in
• Dimension - Outside Diameter inch: 0.821 in
• Package Height: 0 in
• Package Length: 0 in
• Package Weight: 0 lb
• Package Width: 0 in
• Voltage - Maximum: 35000
• Conductor - Copper Str Run: 500 kcmil
• Conductor - Copper Str Run Range: 500 kcmil
• Conductor - Copper Str Size Range: 250 kcmil
• Conductor - Copper Str Tap: 250 KCMIL
• Conductor - Copper Str Tap Range: 250 kcmil
• Conductor - Material: COPPER
• Conductor Type: CODE
• Wire Size: 250 kcmil
• Certification - CSA Approved: No
• Certification - cULus: No
• Certification - ETL: No
• Certification - UL Recognized: No
• Standards - RoHS Compliance Status: CM
• UL Listed: No
