Bussmann fnqr8/10

Overview

Bussmann CC-Tron® FNQ-R-8/10 Current Limiting High Inrush Time Delay Fuse, 0.8 A, 600 V, 200 kAIC Interrupt, CC Class, Cylindrical Body

Product Specifications

• Catalog Number: FNQ-R-8/10
• UPC / GTIN: 051712147026
• Manufacturer Brand: Eaton Bussmann series
• UNSPSC: 39121606
• Features: Time delay compatible with inrush characteristic of small control transformers; Current limitation at class CC levels provides maximum component short circuit current protection; 200 kA interrupt rating provides high ratings at all circuit locations; Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse; Nickel plated brass end caps
• Amperage Rating: 0.8 A
• Body Size: 13/32 in Dia x 1-1/2 in L
• Body Type: Cylindrical
• Class: CC
• Country of Origin: Mexico
• Element: Dual
• Indicating/Non-Indicating: Non-Indicating
• Interrupt Rating: 200 kAIC
• Material: Melamine Tube
• Mounting Type: Holder
• Rejection/Non-Rejection: Rejection
• Response Time: 12 s at 200%
• Series: FNQ-R
• Terminal Type: Ferrule End
• Type: Current Limiting High Inrush Time Delay
• Voltage Rating: 600 V
