Crouse-Hinds BHP3585-NW 4W 5P 30Amp Plug

Overview

Crouse-Hinds BHP3585-NW 4W 5P 30Amp Plug

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES BHP PLUG, 30A, 0.875-1.375" CABLE DIAMETER, FOUR-WIRE, FIVE-POLE, BRASS CONTACTS, 60-400 HZ, STYLE 2, COPPER-FREE ALUMINUM, 480 VAC
• Full Technical Description: Natural Copper Free Aluminum Material; 0.875 Inch min. Cable Outer Diameter; 1.375 Inch Max. Cable Outer Diameter; 4 Wire(S); UL 1010 Approval; 480 VAC Voltage Rating; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group F G, Class III, NEMA 3/4/7B/7C/7D/9F/9G/12 Enclosure; 30 Ampere Current Rating; 5 Pole(S); Bhr Mating Receptacle; CROUSE-HINDS[R] Brand; Applicable Standard ANSI; With Cable Grip, Neoprene Bushing; BHP Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Pin And Sleeve Plug
• Unspsc: 39121402
• UPC 12 Digit: 782274043074
• SKU Name: crsh bhp3585nw
