Crouse-Hinds EDS218SA 1-Gang Enclosure W/2P Switch

Overview

Crouse-Hinds EDS218SA 1-Gang Enclosure W/2P Switch

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES EDS SNAP SWITCH CONTROL STATION, 20A, WITH SWITCH, WITH ONE 3/4" HUB, COPPER-FREE ALUMINUM, 1, SINGLE-GANG, TWO-POLE, 2, 120-277V, DEAD END, TWO-POLE, 3/4", 120-277 VAC
• Full Technical Description: Dead End Type; 2-Pole Contact Configuration; 3/4 Inch Hub Size; Natural Finished Copper Free Aluminum Enclosure Material; UL 1203, CSA C22.2 Approval; 120/277 VAC Voltage Rating; Class I Div 1 and 2, Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G Enclosure; 20 Ampere Current Rating; Explosionproof, Dust-Ignitionproof, Raintight; Front Operated Lever Operator Type; Black Nylon 6/6 Actuator Material; Single Gang Box Type; Applicable Standard CEC, NEC; Shaft Material Natural Finished Stainless Steel; Application Wet Location; EDS Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Tumbler/Snap Switch Control Station
• Unspsc: 39122209
• UPC 12 Digit: 782274535531
• SKU Name: crsh eds218sa

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
