Crouse-Hinds EDSC3240 2-Gang Enclosure W/4Way Switch

Overview

Crouse-Hinds EDSC3240 2-Gang Enclosure W/4Way Switch

Product Specifications

• Full Technical Description: Feed-Through Type; 4-Way Contact Configuration; 1 Inch Hub Size; Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy Enclosure Material; UL 1203, CSA C22.2 Approval; 120 to 277 Volt AC Voltage Rating; Class I Div 1 and 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G Enclosure; 20 Amp Current Rating; Dust Ignitionproof, Explosionproof, Rain Tight, Wet Location; Front Operated Lever Operator Type; Black Nylon 6/6 Actuator Material; 2-Gang Box Type; Shaft Material Natural Stainless Steel; Applicable Standard CEC, NEC; EDS Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Tumbler/Snap Switch Control Station
• UPC 12 Digit: 782274766003
• SKU Name: crsh edsc3240

Resources

• Manufacturer Spec Sheet
