Crouse-Hinds EFD3594 Enclosure W/Thumb Switch

Overview

Crouse-Hinds EFD3594 Enclosure W/Thumb Switch

Product Specifications

• Full Technical Description: Dead End Type; 3-Way Contact Configuration; 1 Inch Hub Size; Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy Enclosure Material; UL 1203, CSA C22.2 Approval; 120/277 VAC Voltage Rating; Class I Div 1 and 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G/12 Enclosure; 30 Ampere Current Rating; Explosionproof, Dust-Ignitionproof, Raintight; Front Operated Lever Operator Type; Natural Stainless Steel Actuator Material; Single Gang Box Type; Applicable Standard CEC, NEC; Application Wet Location; Size 6-3/32 Inch L X 3-1/2 Inch W X 3-1/16 Inch D; EFD Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Tumbler/Snap Switch Control Station
• UPC 12 Digit: 782274271200
• SKU Name: crsh efd3594

Resources

• Manufacturer Spec Sheet
