Crouse-Hinds EYSR6 2" Conduit Seal

Overview

Crouse-Hinds EYSR6 2" Conduit Seal

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES EYSR RETROFIT SEALING FITTING, FERALOY IRON ALLOY, 2"
• Full Technical Description: Drain, Hub Type; Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy/Ductile Iron Material; Female Connection Type; UL 1203, CSA C22.2 Approval; Class I Div 1 Group C D, Class I Div 2 Group C D, Class II Div 1 Group E F G, Class II Div 2 Group E F G Enclosure; 2 Inch Trade Size; Horizontal/Vertical Mounting Position; Constructional Feature Explosionproof, Dust Ignitionproof; Overall Dimension 6.25 Inch Length X 3 Inch Width X 4 Inch Height; Material Electrogalvanized Steel (Pipe Plug, Bolt, Set Screw), Neoprene (Gasket); Internal Volume 25-3/4 Cubic Inch (Vertical), 40-1/2 Cubic Inch (Horizontal); Application Hazardous/Classified Location; EYSR Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Conduit Seal
• Unspsc: 39121311
• UPC 12 Digit: 782274793436
• SKU Name: crsh eysr6

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
