Crouse-Hinds EYSR8 3" Seal Fitting

Overview

Crouse-Hinds EYSR8 3" Seal Fitting

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES EYSR RETROFIT SEALING FITTING, FERALOY IRON ALLOY, 3"
• Full Technical Description: Drain, Hub Type; Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy/Ductile Iron Material; Female Connection Type; UL, CSA C22.2 Approval; Class I Div 2 Group C D, Class II Div 2 Group E F G Enclosure; 3 Inch Trade Size; Vertical/Horizontal Mounting Position; Constructional Feature Explosionproof, Dust-Ignitionproof; Material Electrogalvanized Steel (Pipe Plug, Bolt, Set Screw), Neoprene (Gasket); Internal Volume 86-1/2 Cu Inch (Vertical), 126 Cu Inch (Horizontal) Cu Inch (Horizontal); Size 8-1/2 Inch L X 5-1/2 Inch W; EYSR Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Conduit Seal
• Unspsc: 39121311
• UPC 12 Digit: 782274793474
• SKU Name: crsh eysr8
