Crouse-Hinds FSQC2430 30A 3Wr 4P Receptacle

Overview

Crouse-Hinds FSQC2430 30A 3Wr 4P Receptacle

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES ARKTITE FSQC INTERLOCKED RECEPTACLE WITH SWITCH, 30A, THROUGH FEED, THREE-WIRE, FOUR-POLE, BRASS CONTACTS, COPPER-FREE ALUMINUM, SPRING DOOR, 3/4", THREE-POLE SWITCH, 120-600 VAC
• Full Technical Description: Interlocked Type; Copper-Free Aluminum Enclosure/Cover/Spring Door, Krydon Insulator, Brass Contact Material; 3 Wire(S); Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group F G, Class III, NEMA Eemac 3/7B/7C/7D/9F/9G/12 Enclosure; 30 Amp Current Rating; 4 Pole(S); Construction Feature Dust Ignitionproof, Explosionproof, Rain Tight; Includes Spring Door, 3/4 Inch Feed-Trough Hub, 3-Pole Switch; Used on Apj/Npj Arktite Plug; Application Wet Location; FSQC Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Pin and Sleeve Receptacle
• Unspsc: 39121406
• UPC 12 Digit: 782274189888
• SKU Name: crsh fsqc2430
