Crouse-Hinds FSQC3390 3W-4P Receptacle

Overview

Crouse-Hinds FSQC3390 3W-4P Receptacle

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES ARKTITE FSQC INTERLOCKED RECEPTACLE WITH SWITCH, THROUGH FEED, 0.55-0.70" CABLE DIAMETER, THREE-WIRE, FOUR-POLE, BRASS CONTACTS, COPPER-FREE ALUMINUM, SPRING DOOR, 1", FOR USE WITH MAGNETIC MOTOR STARTERS
• Full Technical Description: Interlocked Type; FERALOY[R] Iron Alloy Enclosure, Copper Free Aluminum Spring Door Material; 250 VAC/VDC Voltage Rating; 30 Ampere Current Rating; 4 Pole(S); Dust Ignition Proof, Explosion Proof, Rain Tight; 1 Inch Hub Type; Spring Door; Extra Pole Grounding Style; ARKTITE[R] Brand; Approval UL 1010, CSA C22.2; FSQ Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Pin And Sleeve Receptacle With Disconnect
• Unspsc: 39121406
• UPC 12 Digit: 782274417349
• SKU Name: crsh fsqc3390

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
