Crouse-Hinds HRC2 Explosion-Proof Thermostat

Overview

Crouse-Hinds HRC2 Explosion-Proof Thermostat

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES HRC BIMETAL THERMOSTAT, 0.5 HP/1 HP, COPPER-FREE ALUM, 1-POLE, 2.5F (1.5C) TEMP. DIFF, 36 TO 82F (2 TO 28C) TEMP. RANGE, DOUBLE-THROW, 3/4", FOR HEATING OR COOLING/VENTILATION, 120/250 VAC
• Full Technical Description: 5.92 Inch W X 4.38 Inch D Size; UL 1203, CSA C22.2 Approval; 480 VAC Voltage Rating; 22 Ampere Current Rating; Rectangular, Vertical Cover Type; 36 to 82 Deg F Temperature Rating; 1/2 HP at 120 VAC, 1 HP at 250 VAC Power Rating; Single Pole Double Throw Switch Type; Application Hazardous Location; Constructional Feature Dustproof, Explosionproof, Ignitionproof; Enclosure Type Class I Div 1 and 2 Group C D, Class II Div 1 Group E F G, Class II Division 2 Group F G, Class III; Hub Size 3/4 Inch; Material Natural Finish Copper Free Aluminum; HRC Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Thermostat
• Unspsc: 39121308
• UPC 12 Digit: 782274154619
• SKU Name: crsh hrc2

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
