Crouse-Hinds N2SC1110 Start 1-Pushbutton Station

Overview

Crouse-Hinds N2SC1110 Start 1-Pushbutton Station

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES N2S PUSHBUTTON CONTROL STATION, WITH PUSHBUTTONS, WITH TWO 1/2" HUBS, FIBERGLASS-REINFORCED POLYESTER, SINGLE-GANG, 1, THROUGH FEED, 1/2"
• Full Technical Description: Pushbutton Type; Corrosion Resistant VESTAMID[T] Material; Black Finish; 1NO-1NC Contact Configuration; 600 VAC Contact Rating; UL 508, CSA C22.2 Approval; NEMA 3/4X/7/12, IP66, Class I Div 2 Group B C D, Class I Zone 1 and 2, Class II Div 2 Group F G Enclosure; Start Legend; Momentary Operator Type; 1 Element(S); 1/2 Inch Feed Through Hub Cable/Conduit Entry; Crouse-Hinds. Brand; Application Chemical Plant, Corrosive/Damp/Wet Location, Indoor/Outdoor, Petroleum Refinery, Process Industry; N2SCU Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Heavy Duty Control Station
• Unspsc: 39122217
• UPC 12 Digit: 782274131856
• SKU Name: crsh n2sc1110

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
