Crouse-Hinds N2SC2121U Control Station Enclosure W/Selector Switch

Overview

Crouse-Hinds N2SC2121U Control Station Enclosure W/Selector Switch

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES N2SU SELECTOR SWITCH CONTROL STATION, WITH SELECTOR SWITCH, HIGH IMPACT POLYESTER, TWO POSITION, TWO CIRCUIT, THROUGH FEED, 3/4", 600 VAC
• Full Technical Description: Feed Through Type; 2NO-2NC Contact Configuration; (2) 3/4 Inch Hub Size; Momentary/Maintained Operation Type; Vestamid Molded Polyester Enclosure Material; UL 508, CSA C22.2 Approval; 600 VAC Voltage Rating; Class I Div 2 Group B C D, Class I Zone 1 and 2 Ex De Iib H2, Class II Div 2 Group F G, NEMA 3/4X/7B/7C/7D/12, IP66 Enclosure; Explosionproof, Watertight, Weatherproof, Dusttight, Corrosion Resistant; Pushbutton Operator Type; 2 Position(S); 2 Circuit(S); Krydon [R] Brand; Legend Start/Stop; Application Chemical Plant, Corrosive/Damp/Wet Location, Indoor/Outdoor, Petroleum Refinery, Process Industry; N2SCU Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Selector Switch Control Station
• Unspsc: 39122217
• UPC 12 Digit: 782274113753
• SKU Name: crsh n2sc2121u

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
